Quality Controll In Firstmold

0
QC Personnel
0
QC Equipments
0
Certificate
0
Certificate
Machines

Perfect measuring machines

CMMs, quadratic element vision measures, high gauges, pressure gauges, material testors, roughness inspectors, fluorescent light testors, etc.
Coordinate Measuring Machine

It can obtain the discrete position of the space point of the measured part through the coordination of the detection sensor and the measurement of the spatial axis movement. Then complete the analysis and inspection work through a mathematical calculation.

QC machine CMM
Quadratic Element Vision Measure

It is used to measure the dimensions of products or molds(including position, concentricity, straightness, contour, roundness, dimensions, etc.) It is mainly used for two-dimensional plane inspection of thinner products (such as shrapnel) and smaller products.

QC Machine Projector
High Gauge

High gauge is an instrument used to measure the height of products or mold parts. It is widely used in online or mass measuring. It can measure the height, depth, slot width, inner and outer diameter, hole center distance, axis center distance, flatness, verticality, etc.

QCmachine High Gauge
ISO 9001:2015
Management

ISO 9001:2015

The international common quality management system is the guarantee of our product quality.

More Quality Control Capabilities

More Firstmold shows will help you get to know our QC abilities better.

Pressure Gauge

Testing whether the compressive properties of materials and finished products meet certain standards

Moisture Analyzer​

Testing the moisture content in plastic raw materials, which is especially important for plastic products

Color Controller

Check whether the color of raw materials or plastic parts deviates from the customer's requirements

XRF Analyzers

Detects the content of specific metals in products or raw materials, such as aluminum, copper, etc.

XRF Spectrometer

Detecting the presence of radioactive substances and harmful substances in products or raw materials

Volutpat pede gravida senectus sollicitudin primis diam fringilla parturient rutrum dis sem.

Equipment Name Brand Precision Amount
CMM
SEREIN CROMA1086
(2.8+L/300)μm
2
CMM
SEREIN CROMA686
(2.8+L/300)μm
1
Quadratic Element Vision Measure
HEXAGON EAGLE S432
(3.0+L/200)μm
2
Quadratic Element Vision Measure(Auto)
HEXAGON VIEWMAX C432
(3.0+L/200)μm
1
HIGH GAUGE
TESA HITE700
(2.8+L/300)μm
3
HIGH GAUGE
MITUYOYO QM-HEIGHT 600
(2.8+L/300)μm
1
Material Testor
OLYMPUS DPO-2000
1PM
1
Roughness Inspector
MITUYOYO SJ-210
± 7μm
1
XRF Spectrometer
EDX 1800B
± 0.05%
1
